 NEW  | UH | UQ | CTH | COE | COQ | CBQ | CBH | CPH | PH | TSH

New in Glary

Powerful Modules Powering Your World!



Features

EN55022 Class B

Ultra high efficiency    -- 92%@12V/3A

                                    -- 90%@5.0V/8A

                                    -- 88%@3.3V/10A

High power density ----------- 40W/in3

Potted six sided metal enclosed package

Compatible pin assignment

2.0" X 1.0" X 0.40" Packaging



Specifications
Tightly regulated output, typical ±3%
Output voltage adjustment trim +/-10%
Load regulation ± 1%
Line regulation ± 1%

Output tolerance band ± 4%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 1%(Vrated)
---– Peak to peak 3%(Vrated)

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote
ON/OFF control



40W/10A High Reliability 2"×1" Power Module



Free Aurora Sample

Data Sheet of Aurora Converter



News Release



October 29, 2010









Applications
Wireless networks access

Optical network equipment
Enterprise networks
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length



The AB series high efficiency power module is the first series of Glary next generation Aurora Converter family.  It provides 40W/10A output with industry standard 2" × 1" metal package, which is designed with the efficiently patented “Coupled-Inductor SR” topology.  The low profile module design with silicone potted metal package eliminates the hot spots and further secures better thermal performance.







Features

Ultra high efficiency    -- 92%@12V/2.5A

                                    -- 90%@5.0V/6A

                                    -- 90%@3.3V/8A

High power density ----------- 100W/in3

Open frame package

Industry standard 1/16 brick pin out definition

Outline foot print: 0.9" X 0.91" X 0.32"



Specifications
Tightly regulated output, typical ±2%
Output voltage adjustment trim +/-10%
Load regulation ± 0.5%
Line regulation ± 0.5%

Output tolerance band ± 4%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 1%(Vrated)
---– Peak to peak 3%(Vrated)

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing



30W/8A High Reliability 1/32 Brick Module



Data Sheet of Neat Converter



News Release



October 28, 2010









Applications
Wireless networks access

Optical network equipment
Enterprise networks
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length



The NT series high efficiency power module is the first series of Glary next generation Neat Converter family.  It provides 30W/8A output with 1/32 brick package, which is designed with the efficiently patented “Coupled-Inductor SR” topology.  The low profile module design with open frame package reduces the shadow effect and provides the improved thermal performance to simplify the system power design.







Features

Ultra high efficiency    -- 92%@28V/18A

                                    -- 92%@12V/42A

High power density ----------- 144W/in3

Six sided metal enclosed with potting

IStandard full brick pin out compatible

Outline foot print: 2.66" X 2.62" X 0.5"



Specifications

Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 1%Vo
---– Peak to peak 3%Vo

Recommended  temperature range:

                              ----- 40°C to 110°C
3000Vdc isolation voltage
Remote output voltage sensing



300V Input 500W/42A Metal Enclosed Half Brick Module



Data Sheet of UH2H Module



News Release



October 27, 2010









Applications
Scalable power system

Semiconductor Test

Telecom
High Performance Computing
Server



Options
Remote on/off control logic
Pin length

Current share function



The UH2H series provides up to 500W/42A outputs with industry standard half brick package. The efficient SR stage is combined with patented Buck Reset” topology for reduce power loss to achieve 144W/in3 power density. The multi-layer single side circuit board design plus the patented Sink-Plate technology is able to enhance the thermal performance and improve its reliability. Modules are designed for Telecom, Servers, Networking equipments and other applications that use a 300V (200~400V) input bus.







Features

Ultra high efficiency    -- 92%@48V17A

                                    -- 92%@28V/29A

                                    -- 92%@12V/67A

                                    -- 89%@3.3V/140A

High power density ----------- 298W/in3

Lowest total height --------- 0.46" (11.4mm)

Open frame package

Industry standard pin out compatible

Half brick size: 2.43" X 2.40" X 0.46"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 1%Vo
---– Peak to peak 3%Vo

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing



800W/140A Half Brick Module



Data Sheet of UH800W Module



News Release



October 27, 2010  PowerPulse.Net









Applications
Semiconductor Test

Telecom
High Performance Computing
Server



Options
Remote on/off control logic
Pin length



The UH series provides up to 800W/140A outputs with industry standard half brick package. The efficient SR stage is combined with patented “Buck Reset” topology for reduce power loss to achieve 298W/in3 power density. The multi-layer single side circuit board design plus the patented Sink-Plate technology is able to enhance the thermal performance and improve its reliability. Modules are designed for Telecom, Servers, Networking equipments and other applications that use a 48V (36~75V) input bus.







Features

Ultra high efficiency    -- 92%@48V/32A

                                    -- 92%@28V/54A

                                    -- 92%@24V/63A

High deliver power  ------------------- 1500W

Six sided metal enclosed package with potting

Industry standard full brick pin out compatible

Outline foot print: 5.0" X 4.8" X 0.75"



Specifications
Tightly regulated output, typical ±2%
Output voltage adjustment trim +/-10%
Load regulation ± 0.5%
Line regulation ± 0.5%

Output tolerance band ± 4%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 1%(Vrated)
---– Peak to peak 3%(Vrated)

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing



1500W/100A Scalable PowerSquare Series 2X Brick Module



Data Sheet of PS Series



ECNmag.com November 19, 2008









Applications
Scalable power system

Semiconductor Test

Telecom
High Performance Computing
Server



Options
Remote on/off control logic
Pin length

Current share function



The PowerSquare series provides up to 1500W/100A outputs with industry standard full brick pin assignment. The high thermal conductivity silicone potted six-sides metal package is designed for applications under extreme environmental conditions. The efficient SR stage is combined with patented “Buck Reset” topology for reduce power loss to achieve 83W/in3 power density. The multi-layer single side circuit board design plus the unique module structure is able to enhance the thermal performance and improve its reliability. Modules are designed for Industrial, Telecom, Servers, Networking equipments and other applications that use a 300V (200V~400V) input bus.







Features

Ultra high efficiency -- 92%@5V/80A

                                 -- 91%@5V/100A

Maximum power density ----------- 200W/in3

Lowest total height --------- 0.43" (10.9mm)

Open frame package with Sink-Plate

Industry standard pin out compatible

Half brick size: 2.43" X 2.40" X 0.43"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 40mVrms (5.0V)
---– Peak to peak 150mVpk-pk (5.0V)

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing



UH48050N20B-A0 Half Brick Modules With Sink-Plate

UH48050ABCD-A0R0007



PowerPulse.Net July 18, 2005









Applications
Semiconductor Test

Telecom
High Performance Computing
Server



Options
Remote on/off control logic
Pin length



The UH48050N20B-A0 module is a new  generation of DC/DC power modules designed for high efficiency and high current density. It provides 5V-100A output with 90% efficiency in an industry standard half brick footprint, It features double pin configuration, which makes it an ideal choice for high power, high current and high density applications.

The innovative hot spot free Sink-Plate structure with ultra high efficiency circuit design gives module good reliability at high temperature environment.





Features

Ultra high efficiency -- 92%@12V/15A

                                 -- 91%@12V/21A

High power density ------------ 96W/in3

Lowest total height --------- 0.75" (19.0mm)

Open frame package with Sink-Plate

Industry standard pin out compatible

Half brick size: 2.3" X 1.5" X 0.75"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 40mVrms (5.0V)
---– Peak to peak 150mVpk-pk (5.0V)

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing



UQ48120N20F-21 Quarter Brick Modules With Sink-Plate

 UQ48120N20F-21R0005





PowerPulse.Net July 18, 2005

Electronic products September, 2005





Applications
ATCA

Servers
Enterprise networks
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length



The UQ48120N20F-21 provides up to 250W output current with 91% efficiency in an industry standard quarter brick with Sink-Plate technology, the new generation DC/DC module was special designed to enhance its derating performance with high efficiency and high current density.

The deep trenched Sink-Plate technology was attached as an integrated heat sink helps the module operate under extreme environments with the lowest total height to deliver maximum available power with no heat sink.

The innovative hot spot free construction technique with Sink-Plate design gives this converter good reliability at high temperature operation.

Features

Ultra high efficiency -- 89%@3.3V/70A

                                 -- 86%@1.8V/100A

High current density ------------ 42A/in3

Low profile --------- 0.42" (10.6mm)

Open frame package with Sink-Plate

Industry standard pin out compatible

Half brick size: 2.3" X 2.4" X 0.42"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 40mVrms (5.0V)
---– Peak to peak 150mVpk-pk (5.0V)

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing



CPH Series Half Brick Modules With Sink-Plate

 CPH48120ABCD-25R0105





PowerPulse.Net April 08, 2005

Electronic products May, 2005

Applications
Wireless networks access

Optical network equipment
Enterprise networks
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length



The CPH provides up to 100A output current with 86% efficiency in an industry standard half brick with Sink-Plate technology are a new generation of DC/DC converters were designed to enhance its derating performance with high efficiency high current density.

The Sink-Plate technology helps the module operate under extreme environments to deliver high power with an integrated heat sink, but retains the capability for mounting to external cooling assemblies such as heat sinks, heat pipes or chassis back planes

which makes it an ideal choice for small space, high current and high temperature applications. The innovative hot spot free construction technique with Sink-Plate design gives this converter good reliability at high temperature operation.

Features

Ultra high power

                    ----- 89%@3.3V-120A

                    ----- 90%@3.3V-100A

High power density ------------ 170W/in3

Very low profile --------- 0.40" (10.2mm)

Open frame package with base-plate

Industry standard pin out compatible

Eighth brick size: 2.43" X 2.40" X 0.40"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 40mVrms (3.3V)
---– Peak to peak 150mVpk-pk (3.3V)

Recommended  temperature range:

                              ----- 40°C to 105°C
2000Vdc isolation voltage


UH Series Ultra High Power Half Brick

UH48033ABCD-120R0004





PowerPulse.Net October 29, 2004

Applications
Server computing

Data Communication
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length

Pin number

Base Plate



The UH-series dc-dc converters are a new  generation of DC/DC power modules designed for high efficiency and high current density. The UH provides up to 120A output current with 90% efficiency in an industry standard half brick with double pin configuration, which makes it an ideal choice for high power, high current and high density applications. The innovative hot spot free construction technique with ultra high efficiency circuit design gives this converter good reliability at high temperature operation.

Features

Ultra high efficiency

             ----- 90%@5.0V-25A/3.3V-25A

             ----- 88%@3.3V-25A/1.8V-25A

High power density ------------ 125W/in3

Very low profile --------- 0.34" (8.6mm)

Open frame package with base-plate

Industry standard pin out compatible

Eighth brick size: 2.3" X 2.40" X 0.34"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 40mVrms (5.0V)
---– Peak to peak 150mVpk-pk (5.0V)

Recommended  temperature range:

                              ----- 40°C to 105°C
2000Vdc isolation voltage

CTH Series High Efficiency Half Brick

(Two Converters Inside)

CTH485033N20M-1515R0103





PowerPulse.Net June 15, 2004

Electronic products June 25, 2004



Applications
Wireless networks access

Optical network equipment
Enterprise networks
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length

Height

Base Plate



The CTH-series dc-dc converters are a new generation of DC/DC power modules designed for high efficiency and high current density. No mutual interference between two outputs during load  transient and synchronous ripple/noise characteristic make it suited for replace two conventional bricks with better performance. The CTH series provides up to 25A+25A real outputs with 90% efficiency in an industry standard half brick, which makes it an ideal choice for small space, high current and low voltage applications. The innovative hot spot free construction technique with ultra high efficiency circuit design gives this converter good reliability at high temperature operation.

Features

Ultra high efficiency -- 88%@1.8V/40A

                                 -- 86%@1.8V/50A

High current density ------------ 71A/in3

Very low profile --------- 0.34" (8.6mm)

Open frame package with base-plate

Industry standard pin out compatible

Eighth brick size: 2.3" X 0.90" X 0.34"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 40mVrms (5.0V)
---– Peak to peak 150mVpk-pk (5.0V)
Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing

COE Series High Efficiency Eighth Brick

COE48018ABCD-50



PowerPulse.Net October 10, 2003

Electronic products December 01, 2003





Applications
Wireless networks access

Optical network equipment
Enterprise networks
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length

Height

Base Plate



The COE-series dc-dc converters are a new generation of DC/DC power modules designed for high efficiency and high current density applications. The COE48018ABCD-50 provides up to 50A output with 86% efficiency in an industry standard eighth brick, which makes it an ideal choice for small space, high current and low voltage applications. The innovative hot spot free construction technique with ultra high efficiency circuit design gives this converter good reliability at high temperature operation.

Features

Ultra high efficiency -- 90%@1.8V/60A

                                 -- 87%@1.8V/100A

                                 -- 92%@5.0V/30A

                                 -- 91%@5.0V/50A

High current density ------------ 86A/in3

Very low profile --------- 0.35" (8.9mm)

Open frame package with base-plate

Industry standard pin out compatible

Quarter brick size: 2.3" X 1.45" X 0.34"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 40mVrms (5.0V)
---– Peak to peak 150mVpk-pk (5.0V)

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing

 CPQ Series High Power Quarter Brick

CPQ48S018-100 CPQ48S050-50





Electronic products March 01, 2003

PowerPulse.Net December 04, 2002

PowerPulse.Net October 25, 2002

PowerPulse.Net August 27, 2002

Applications
Wireless networks access

Optical network equipment
Enterprise networks
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length



The CPQ-series dc-dc converters are a new generation of DC/DC power modules designed for high efficiency and high current density. The CPQ provides up to 1.8V/100A output with 87% efficiency or 5.0V/250W output with 91% efficiency in an industry standard quarter brick, which makes it an ideal choice for small space, high current and low voltage applications. The innovative hot spot free construction technique with ultra high efficiency circuit design gives this converter good reliability at high temperature operation.

Features

Ultra high efficiency -- 89%@1.8V/30A

                                 -- 90%@2.5V/30A

High power density ------------ 88W/in3

Very low profile --------- 0.34" (8.6mm)

Open frame package with base-plate

Industry standard pin out compatible

Quarter brick size: 2.3" X 1.45" X 0.34"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 40mVrms (5.0V)
---– Peak to peak 150mVpk-pk (5.0V)

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing

COQ Series High Efficiency Quarter Brick

COQ48025ABCD-40R0004





PowerPulse.Net July 09, 2002

Electronic products September 01, 2002

Applications
Wireless networks access

Optical network equipment
Enterprise networks
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length



The COQ-series dc-dc converters are a new generation of DC/DC power modules designed for high efficiency and high current density. The COQ provides up to 30A output with 89% efficiency in an industry standard quarter brick, which makes it an ideal choice for small space, high current and low voltage applications. The innovative hot spot free construction technique with ultra high efficiency circuit design gives this converter good reliability at high temperature operation.

Features

Ultra high efficiency -- 89%@3.3V/60A

                                 -- 87%@1.8V/80A

High current density ------------ 42A/in3

Very low profile --------- 0.34" (8.6mm)

Open frame package with base-plate

Industry standard pin out compatible

Half brick size: 2.3" X 2.4" X 0.34"



Specifications
Tightly regulated output, typical ±1%
Output voltage adjustment trim +/-10%
Load regulation ± 0.2%
Line regulation ± 0.2%

Output tolerance band ± 3%
No minimum load required
Ripple and noise (20MHz BW)
---– RMS 40mVrms (5.0V)
---– Peak to peak 150mVpk-pk (5.0V)

Recommended  temperature range:

                              ----- 40°C to 110°C
2000Vdc isolation voltage
Remote output voltage sensing

CPH Series High Power Half Brick





PowerPulse.Net May 09, 2002

Electronic products July 01, 2002

Applications
Wireless networks access

Optical network equipment
Enterprise networks
Latest microprocessor powered applications



Options
Remote on/off control logic
Pin length



The CPH-series dc-dc converters are a new generation of DC/DC power modules designed for high efficiency and high current density. The CPH provides up to 80A output current with 87% efficiency in an industry standard half brick, which makes it an ideal choice for small space, high current and low voltage applications. The innovative hot spot free construction technique with ultra high efficiency circuit design gives this converter good reliability at high temperature operation.



Home | Company | Products | Service | Future | Publish | News | Competitor | Resource

 NEW  | UH | UQ | CTH | COE | COQ | CBQ | CBH | CPH | PH | TSH

Glary Power Technology Company Limited  Phone: 886-4-23507467 Fax: 886-4 23506841 http://www.glary.com

 No. 51,  Ind. Park 42nd Rd. Hsi-Tun Dist Taichung TAIWAN R.O.C.
